SIM5400 | E510 | Buy UHF RFID Module Online | SILION TECH
The 16-port RFID module SIM5400 is based on the next-generation Impinj E510 RAIN RFID reader chip. The SIM5400 module can be used for multiple antenna time-sharing applications; when the 8dBi antenna is used, the reading distance is more than 12 meters; the excellent multi-label anti-collision algorithm, the inventory is more than 600tags/s; the large-area aluminum alloy thermal conductive panel is used. Excellent heat dissipation.
If the SIM5400 has piqued your interest,Contact Us Now！
Product Description
Based on the new generation Impinj E510 reader chip.
Support EPC global UHF Class 1 Gen 2 (ISO 18000-6C).
33dBm RF output.
16 SMA connectors, support 16 antennas.
High-performance anti-collision recognition algorithm.
Real-time temperature monitoring.
The metal shell is good for heat dissipation.
Small size, can be easily integrated into different types of RFID equipment, such as filing cabinets, tool cabinets, smart shelves.
Parameter
Hardware and OS
- API SupportC, C#/.NET, Java
Physical Characteristics
- Dimensions181.5mm × 83.6mm × 8mm
- Weight248g
RFID Characteristics
- Air ProtocolsEPC Class 1 Gen 2 (ISO 18000-6C)
- ChipsetImpinj E510
- FrequencyUSA: 902-928MHz FCC (NA, SA)
EU: 865-868MHz (ETSI)
CN: 920-925MHz
Open: 860-960MHz - RF Output Power5dBm-30/33dBm (±1dB) adjustable
- Channel Bandwidth60 dB
- Work ModeFixed / hop frequency optional
- Sensitivity-78dBm
- Programing FunctionsTag RSSI Support
Antenna Detector Support
Temperature Detector Support
Connectivity
- Communications15 pin MOLEX53261-1571 Connector
UART serial port (TTL),
Baud rate 9600~921600bps - General Purpose I/O2 Inputs (DC 0~3.3V)
2 Outputs (DC 0~3.3V)
- Communications15 pin MOLEX53261-1571 Connector
Antenna
- Antenna Ports16 ports, 50Ω SMA Connectors
Performance
- Reading Distance≥13m with 8dBi antenna
- Anti-collision≥600 tags/s
Power
- Power SupplyInput Voltage: 5.0V DC+/-5%
Power consumption in
RF output mode: 15W（MAX）,@5V, 33dBm
Power consumption in standby: 0.6W
- Power SupplyInput Voltage: 5.0V DC+/-5%
Environmental
- Operating Temp.-25°C to +65°C
- Storage Temp.-40°C to +85°C
- Humidity5-95% Non-condensing (+25°C)
